The HMC1000 is a powerful horizontal CNC machining center for larger and heavier workpieces. The 1000 × 1000 mm table, 1500 kg load capacity and BT50 spindle taper suit demanding production machining.
1000 × 1000 mmTable size
1600/1000/1000 mmX/Y/Z travel
1500 kgMax table load
Description
The HMC1000 is the HMC series model with the larger table and higher load capacity, suited to precise machining of larger workpieces. The 1000 × 1000 mm table and 1500 kg load capacity give more options for heavier production parts.
- Large table 1000 × 1000 mm working area for larger workpieces
- Higher load capacity Max table load up to 1500 kg
- Strong machining BT50 spindle taper and 15/18.5 kW spindle power
Suitable if…
- you need to machine larger or heavier workpieces
- a 1000 × 1000 mm table is important
- workpiece weight can reach up to 1500 kg
Before you choose
- whether your workpiece dimensions fit the 1000 × 1000 mm table
- whether the required machining fits within the 1600/1000/1000 mm travel range
- whether the machine weight of 18,000 kg suits the planned installation site
The HMC1000 is the right choice if the priority is a larger table and higher load capacity compared with the HMC630A and HMC800.
Technical data
| Model | HMC1000 |
|---|---|
| Table size | 1000 × 1000 mm |
| X/Y/Z travel | 1600/1000/1000 mm |
| Spindle taper | BT50 |
| Spindle power | 15/18.5 kW |
| Max table load | 1500 kg |
| Machine weight | 18,000 kg |
