The XK7113A is a very compact solution for training, workshop jobs and machining small parts. A 400 × 140 mm table, ER20 spindle taper and 0.4 kW spindle power suit simpler, lighter-duty work.
400 × 140 mmTable size
220/120/200 mmX/Y/Z travel
125/155 kgMachine weight
Description
The XK7113A suits situations that call for a small, easy-to-install machine for learning, testing or lighter metalworking. An ER20 spindle taper, 3000 rpm spindle speed and a machine weight of 125/155 kg make it suitable for a smaller working environment.
- Very compact 400 × 140 mm table for small parts
- ER20 spindle taper Suited to lighter precision work
- Easy to install Machine weight 125/155 kg
Suitable if…
- you need a compact machine for training
- you work with small parts
- installation space is limited
Before you choose
- whether the 400 × 140 mm table is sufficient
- whether the 0.4 kW spindle power suits your planned work
- whether the 220/120/200 mm travel covers the machining area you need
If you need a more powerful spindle in the same format, compare it with the XK7113C and XK7113D.
Technical data
| Model | XK7113A |
|---|---|
| Table size | 400 × 140 mm |
| X/Y/Z travel | 220/120/200 mm |
| Spindle taper | ER20 |
| Spindle power | 0.4 kW |
| Max spindle speed | 3000 rpm |
| Max table load | – |
| Machine weight | 125/155 kg |
